Commercial Headend Equipment

Eight Channel Agile Analog Modulator
• Adds Analog output to a COM2000 or COM3000 System
• Two agile blocks of four consecutive
NTSC channels
• Up to 8 channels in 1 rack Unit
• No Additional COM46/COM51 cards needed
• Agile Modulation
• Simultaneously output to both QAM
(Primary output) and NTSC 8 (secondary
output) from each tuner
• Per Channel adjustable outputs for attenuation
• Remote management and configuration
For properties that cannot make a complete conversion to digital content, the NTSC-8 allows for the content to be output both in digital
format to the QAM as well as an IP output to the NTSC-8 which will provide a NTSC formatted analog output. This replaces any
requirement for a stacked receiver solution using mini-mods to duplicate channels for fitness centers or other TV’s unable to support
HD or SD digital content. The NTSC-8 is completely agile for each of the 8 outputs allowing for flexibility in RF plant management.

Controlled by the COM2000
The NTSC-8 is controlled by the COM2000/COM3000 using the same interface which controls the COM46/COM51 and QAM modulator.
Adjustments for RF output level will assist the installation to best format the output video for each individual deployment.
Model No. NTSC-8 ............................................Call for Pricing

GigE 8 port switch, used with DTV HE GigE 16 port switch, used with DTV HE
• Non-PoE supported model • Non-PoE supported model
• Power supply included • Power supply included
• Model does not support fiber optic ports • Model does not support fiber optic ports
• 8 Gigabit ports • 16 Gigabit ports
The GS108-E-NTSC is a desktop (10/100/1000) Gbps eight-port The GS116-E-NTSC is a layer two desktop managed (10/100/1000)
managed ethernet switch. On top of the plug & play Gigabit Gbps sixteen-port ethernet switch. On top of the plug & play
Ethernet connectivity, these switches also offer essential Gigabit Ethernet connectivity, these switches also offer essential
networking features such as VLAN, QoS, IGMP Snooping, Link networking features such as VLAN, QoS, IGMP Snooping, Link
Aggregation and Port Trunking (16 port or greater models). By Aggregation and Port Trunking (16 port or greater models). By
listening in on the IGMP conversation between hosts and routers, listening in on the IGMP conversation between hosts and routers,
the Gigabit smart managed plus switch can maintain a map as to the Gigabit smart managed plus switch can maintain a map as to
which links need which IP multicast streams, and will be able to which links need which IP multicast streams, and will be able to
forward multicast traffic only to the links that have asked for them forward multicast traffic only to the links that have asked for them
and cut multicast traffic from links that do not contain a multicast and cut multicast traffic from links that do not contain a multicast
listener. listener.
Model No. GS108-E-NTSC .................................Call for Pricing Model No. GS116-E-NTSC ..................................Call for Pricing
