Satellite Distribution Equipment

DIRECTV MFH2™ Single Wire Satellite Distribution System
®

Active SWM Expander Module

Features
Standard Output SWM Module • Holds up to 4 DSWM-30
SWM Module for up to 26 Tuners, Standard Output version for • DSWM provides power to all 6 satellite inputs
properties with home run wiring, Each of the two outputs is • Two power inputs (from PI-29Z)
capable of supplying Signal to 13 tuners.
Requires 1 PI-29Z power supply (sold separately) • Four power outputs (to DSWM-30)
Model No. DSWM-30 ........................................Call for Pricing • Requires 1 PI-29Z power supply for every
two modules (sold separately)
High Output SWM Module • Not compatible with legacy SWM8/16/32 units
SWM Module for up to 26 Tuners, High Output version for • Unused ports are auto terminated
properties with loop through wiring Each of the two outputs
is capable of supplying Signal to 13 tuners. • This unit is suitable for indoor use
Requires 1 PI-29Z power supply (sold separately) Model No. SWM EXPANDR-A-R0-09 ..................Call for Pricing
Model No. DSWM-30HP ....................................Call for Pricing

Outdoor SWM Expander Module
Features
SWM Expander Module to Hold Up to 4 DSWM-30 • Holds up to 4 DSWM-30
Features • DSWM provides power to all 6 satellite inputs
• Holds up to 4 DSWM-30 • Two power inputs (from PI-29Z)
• Six Satellite Inputs • Four power outputs (to DSWM-30)
• Two power inputs (from PI-29Z) • Requires 1 PI-29Z power supply for every two
• Four ground lugs modules (sold separately)
• Wall mountable • Provides LNB Power and can be used as a polarity locker
• Unused ports are auto terminated • Not compatible with legacy SWM8/16/32 units
• Requires 1 PI-29Z power supply for every • Unused ports are auto terminated
two modules (sold separately) • This unit is suitable for outdoor use with
• Will not power the LNB, external polarity locker is required the D2 Lite Enclosure
• Not compatible with legacy SWM-8/16/32 units Model No. SWM EXPANDR-O-RO-09 .................Call for Pricing
• For indoor use Power Supply with
Model No. SWM-EXPNDR-P-R0-09 ....................Call for Pricing integrated power
inserter. 29VDC
Model No. PI-29Z .....Call for Pricing
