Satellite Distribution Equipment

Six Line Satellite
Amplifier
Features
• Amplifies six
satellite lines
• 250 - 2150 MHz Seven Line Satellite Trunk Tap
• Automatic level Features
controlled output
• Four ground lugs • Six satellite inputs, 250-2150 MHz
• -12 dB to 0 dB slope adjustment • One Terrestrial input, 5-1000 MHz
• Six individual -10 dBm to 0 dBm gain control adjustments • Five values available: 6, 9, 12, 16 or 20 dB
• Requires 1 PI-29Z power supply (sold separately) • Two ground lugs
• Can be powered from individual power input or • DC Power passing from output to input
from Satellite Out port 1 • DC Power blocking on tap ports
• Power output to power device above from either • For indoor use only
individual power out port or Satellite In port 1 • Wall mountable
• Will not power the LNB, external polarity locker is required
• For indoor use only STTAP Series
• Wall mountable Models Description Price
Model No. STA-R0-09 .......................................Call for Pricing STTAP06-R0-09 Seven Line 6 dB Tap Call for Pricing
Six Line Satellite STTAP09-R0-09 Seven Line 9 dB Tap Call for Pricing
Amplifier STTAP12-R0-09 Seven Line 12 dB Tap Call for Pricing
Features STTAP16-R0-09 Seven Line 16 dB Tap Call for Pricing
• Amplifies six STTAP20-R0-09 Seven Line 20 dB Tap Call for Pricing
satellite lines
• Indoor 250
to 2150 MHz A B
• Automatic gain controlled output user adjustable
from -16 dBm to -25 dBm @ 2150 MHz.
• Slope is field selected to either 12 dB or 8 dB
• PI-29Z Power supply sold separately
Model No. TAMP6R03-PI29 ..............................Call for Pricing

Six line LNB Polarity Locker
Six line LNB polarity locker, C D
35 dB port to port isolation,
requires PI-29Z power
supply (sold separately), Grounding Blocks and Lugs
All ports DC passing toward ODU. Model No. Description Price
Model No. DTV6PWRPOL-02 ............................Call for Pricing Single Grounding Block with two set Call for
A GB-1UL screws for two separate ground wires, Pricing
Six line LNB Polarity Locker 5-3,000 MHz, UL Listed
PI-29Z power supply required & sold separately B 200-279 Dual Grounding Block with two set screws Call for
for two separate ground wires, 5-3,000
Model No. PLPI-R0-09 ......................................Call for Pricing MHz, UL Listed Pricing
Quad Grounding Block with two set screws
Power Supply with integrated C GRD BLK 4 W BOOT for two separate ground wires, with Call for
power inserter. 29VDC weather boots, 5-3,000 MHz, UL Listed Pricing
Model No. PI-29Z .......... Call for Pricing D AGC-3 Single grounding lug with hole for ground Call for
screw and seizing screw
Pricing
