Satellite Distribution Equipment

Ka/Ku Satellite Distribution Equipment

Single Line Amplifiers Six Line Amplifiers

A B 6 Line Satellite Amplifier
Single Line Amplifier • 54 - 2,150 MHz Forward • -18 dBm Maximum input
• 14 dB Gain, 6 dB slope • Perfect for amplification of • 2 - 40 MHz Return • Requires PI-29Z power
• 54-3,500 MHz forward any single satellite line • 9 dB to 16 dB Sloped gain supply (sold separately)
• 2-40 MHz return including SWM applications from 54 2,150 MHz
• Power supply PS242000 Model No. LA146R-PI29 ..............................................$124.99
required and sold separately Satellite Diplexer

A. Model No. LA-141R................................................... $54.00

Single Line Amplifier
• 54 - 2,400 MHz Forward • 10 / 15 dB Selectable slope
• Selectable fixed output • -40 dBm Minimum input
of +1, 5 or 10 dBm • Power supply included Satellite Diplexer

B. Model No. PAL1510-T ..............................................$135.99 Intended for CATV and SWM separation or combining where
isolation is less critical. Features low in-band insertion loss. SWM
Dual Line Amplifier control 2.3 MHz and MRV/DECA isolation is 35 dB minimum.
A. Model No. SD-SWMD2 ................................................ $7.25
Satellite Diplexer
Intended for CATV and SWM isolation where both 2.3 MHz and
MRV filtering is critical. The D3 adds a band reject filter at 475 to
625 MHz.
B. Model No. SD-SWMD3 ..............................................$12.00

Dual Line Amplifier 3 Input Amplifier
• 28 dB Gain • 2-42 MHz return • 95 - 2150 MHz,
• 54 - 3,000 MHz Forward • Power supply included • 14 dB gain, 2-4 MHz return
Model No. LA282R-T.................................................... $82.00 • DC and 22 kHz passing

Model No. LA143 ..........................................................$65.00

24VDC Coaxial Power Supply
This power supply allows a SWM
multiswitch in a DIRECTV installation
to be powered from the closet without
Four Line Satellite Distribution Taps generating excessive heat. This power
Models Tap Loss Price inserter couples regulated DC voltage
SD-MST406 6 dB $37.99 on satellite TV coax cables while
SD-MST409 9 dB $37.99 allowing the DBS signal to pass through the inserter.
SD-MST412 12 dB $37.99
SD-MST416 16 dB $37.99 Model No. PS242000 .................................................. $25.00
