Satellite Distribution Equipment

4 Line Power Inserter's

A

SWM Extension Amplifier
• Indoor DBS line powered amplifier with 940 to 2150 MHz B
forward gain and passive 2 MHz to 806 MHz return.
• Boosts SWM 940 to 2150 MHz signals offsetting the loss of
150 feet of RG 6 while bidirectionally passing 2 to 806 MHz
DECA, MoCA and receiver control signals. 4 Line Power Inserter
• MoCA & DECA signals in the 475 to 625 MHz band pass • Supplies LNB power to 4 LNB lines
through the SD SWMA2 • 13V, 18V, 13V with 22KHz & 18V with 22 KHz
• Requires PI-29Z power supply (not included)
• 1 dB of Loss at 2 - 806 MHz, 12 dB gain at 940-1,450 MHz, A. Model No. 4SATPL-PI29 ............................................$42.99
15 dB gain at 1,450 MHz to 2,150 MHz.
Model No. SD-SWMA2-T ...............................................$44.99 4 Line Power Inserter
• Supplies LNB power to 4 LNB lines
Auto Gain Satellite Amplifier • 20 VDC on all 4 lines
• Blocks DC from RF inputs
A • Power supply included
B. Model No. 4SPI-20 ....................................................$66.19

A B C D

HRV Series Vertical Splitters, High Performance,
B 2-2,150 MHz, Diode Steered

4 Line Auto Gain Satellite Amplifier Models Description Price
• Auto gain output of -20 dBm @ 2150 MHz A HRV-S2 1 x 2 Vertical Splitter $4.79
• Accommodates up to four satellite lines B HRV-S3 1 x 3 Vertical Splitter $6.89
• 54 MHz to 2,400 MHz C HRV-S4 1 x 4 Vertical Splitter $8.19
• Power supply included D HRV-S8 1 x 8 Vertical Splitter $14.29
A. Model No. LAL204A-T .............................................$159.00
6 Line Auto Gain Satellite Amplifier
• Auto gain output of -20 dBm @ 2150 MHz
• Accommodates up to six satellite lines
• 54 MHz to 2,400 MHz
• Requires PI-29Z power supply (sold separately)
B. Model No. LAL206A-PI29 .......................................$165.00

HRVT Series Vertical Tap (Directional Coupler)
5 Line Slope Equalizer 1-Port, High Performance, 2-2400 MHz
• Provides 9 dB of slope Models dB Price
• Accommodates up to HRV-T106 6 $4.69
five satellite lines
• 2 MHz to 2,400 MHz HRV-T109 9 $4.69
Model No. 5SEQ9 ... $27.99 HRV-T112 12 $4.69
HRV-T116 16 $4.69
