Meters & Tools
Digital / Analog RF Signal Level Meter
• Direct input by frequency from 54 MHz - 870 MHz
• Direct input by channel number
• DVB average power measurement
• Measures Analog, 8VSB, QAM 64/256, DVB-C, BER & MER
• Simultaneously displays video carrier and audio carrier
strength, and V/A measurement
• Switchable between dBmV and dBµV
• Tilt measurement of three user definable channels
• Carrier-to-noise ratio measurement
• Trunk voltage measurement
• Large 2 5/8" x 1 3/4" dot matrix LCD display with back light
• Battery powered handheld model with internal NiMH
battery and included charger
• Rugged, compact and mobile rubber jacketed housing
• Battery life = 5 hours
The CT-DLM870D is a handheld signal level meter that is designed to provide the most valuable features at reduced cost. It performs
fast and efficiently to take carrier amplitude measurements. It can also take the direct power measurement of DVB signals. This unit
simultaneously displays video carrier, audio carrier strength, V/A measurements, Tilt measurement, C/N measurement and Trunk
voltage measurement. This unit is perfect for balancing digital QAM and analog headend systems, reading digital off air signal levels,
troubleshooting RF distribution systems and taking measurements at individual drops. With the ability to read individual audio and
video carriers along with line voltage and carrier to noise levels, the CT-DLM870D is perfect for all levels of installers and technicians.
Digital / Analog signal level meter Replacement battery
Model No. CT-DLM870D ............................................ $759.00 Model No. CT-DLM870D-BATT ..................................... $42.99
Replacement power supply Interconnect cable to connect CT-DLM870D to a PC
Model No. CT-DLM870D-PS ..........................................$19.99 Model No. CT-DLM-CABLE ............................................$10.00
Plastic Outlet Boxes with Adjustable Screw Mounts
Double Gang
Model No. CT-LVB-DBL
Quantity 1-9 10-99 100-499 500+
Price $1.99/each $1.89/each $1.84/each $1.79/each
Post construction bracket to hold a Single Gang
single gang wall plate when no box is Model No. CT-LVB-SGL
present behind the wall. Wall plate
mounts securely to CT-4101. Quantity 1-9 10-99 100-499 500+
Model No. CT-4101 (MP-4101) ..........$.79 Price $.99/each $.89/each $.84/each $.79/each
800.688.9282 | sales@nace.tv | nace.tv 117
