Equipment Racks & Accessories

ERK Series Enclosures
19" welded stand-alone/gangable enclosures.

Features
• Fully welded construction
• 2,500 lb. weight capacity
• 1/8" thick structural steel internal braces
• UL Listed in the US and Canada
• Seismic certified (when used with ERK-Z4 option) with an Ip value of 1.5
• 22" OD width, available 20", 25" or 28" OD depth
• 1/2", 3/4", 1" & 1-1/2" electrical knockouts on removable split rear plates top and
bottom, easily removable for cable pass through. Top plates additionally include
UHF/VHF knockouts
• Standard front, optional rear 11-gauge 10-32 threaded, fully adjustable rackrail
with numbered rackspace increments
• Key-locked solid rear door standard, optional vented rear doors available
• Optional vented, solid or plexi-glass front doors available
• Configurable top options on 44, 40, and 35 space sizes, solid, vented &
multiple fan tops available
• Durable black textured powder coat finish
• Available in 6 height options from 35.625" to 81.125" overall height
• Optional caster base available

DWR Series Wall Mount Enclosures
Pivoting, sectional wall cabinets ideal for larger systems
in both secured and non-secured areas.
Features
• Available in 17", 22", 26" and 32" overall depths with
15", 20", 24" and 30" of usable depth
• Tool-Free Quick-Mount™ system for easy, one-person
mounting of the center section to the backpan on the jobsite
• New center section rear channel accommodates slim
power to save space
• Optional minimum-clearance latch allows side-by-side
or interior corner mounting
• 16-gauge steel construction with 1/8" thick laser-cut corner braces
• Reversible pad-lockable center section is keyed differently
from optional front door for security
• 2" knockouts, 4" knockouts for Wiremold 4000 Series raceways,
®
and knockouts for UCP Series universal connector panels on side
• Grounding/bonding stud in top and bottom of center section
and backpan facilitates proper grounding and bonding of
electronic equipment, as per NEBS and NEC standards
• Finished in a durable black textured powder coat
• UL listed in the US and Canada
