Commercial Headend Equipment

Analog, SAW Filtered, Fixed Channel Modulator*
Features:
• +55 dBmV RF output
• Available for CATV channels 2-79, 95-99
• Meets FCC Docket 21006 Aeronautical
Frequency Offset Requirements
• Front Panel Accessible Level Controls
for Easy Set-Up and Adjustments
• - 30 dB RF Test output port
• AC Convenience Outlet
The Blonder Tongue BAVM860SAW is an economical commercial quality TV modulator. It provides a +55 dBmV RF output on any
specified CATV channel from 2 to 135 (54 to 860 MHz). HRC and IRC frequency plans are also available. The BAVM860SAW is ideal
for placing A/V program sources such as satellite receivers, VCR’s, DVD’s, cameras or TV demodulators onto standard 6 MHz NTSC TV
channels for broadband distribution. The BAVM860SAW features IF SAW filtering with built-in FCC group delay pre-distortion assuring
excellent adjacent channel performance and color operation. The modulator complies with FCC 21006 with +/- 5 KHz visual carrier
stability and required frequency offsets on all aeronautical channels. For BTSC stereo applications, a field-defeatable audio
preemphasis network is provided making the BAVM860SAW compatible with any outboard stereo generator that provides a
composite baseband output. A -30 dB output test point and all user controls are provided on the front panel.
Model No. BAVM860SAW-* .............................. Call for Pricing
Add Digital Channels To Your Private Cable System!!!

The AQT Converts ATSC Off Air Signals To Digital QAM CATV

8 Channel Off Air/QAM Transcoders AQT8-IP (8x8VSB/QAM to IP)
Converts 8 Off air channels to either QAM, IP or both This unit allows the user to create a customized line up from off-air
and/or cable feeds for IP distribution. The customizable IP output
Features contains up to 20 programs with a combination of SPTS and/or
• Encrypted QAM sources can be mapped to IP MPTS MPTS across eight (8) IP addresses from eight (8) RF input sources.
or SPTS formats in Pass Through mode for Model No. AQT8-IP................................................Call for Pricing
• Remote PHY and Switch Digital applications
• Accepts up to eight RF inputs in 8VSB/QAM format AQT8-QAM (8x8VSB/QAM to QAM)
• Provides one common 8VSB/QAM input port This unit allows the user to create a line up from off-air and/or
with an internal active splitter cable feeds for coax or IP distribution. The unit simultaneously
transcodes eight (8) QAM/8VSB input channels to pass thru (8)
• 2:1 Multiplex Mode to configure eight ATSC 1.0 QAM streams.
off-air channels to four MPTS for QAM Model No. AQT8-QAM .................................Call for Pricing
• PSIP manipulation
• Accepts EAS input in ASI or IP formats AQT8-QAM/IP (8x8VSB/QAM to QAM/IP)
• Supports EAS switching-based on contact closure This unit allows the user to create a line up from off-air and/or
trigger, or +5 to +12 VDC input cable feeds for coax or IP distribution. The unit simultaneously
• Comprehensive GUI-based remote monitoring transcodes eight (8) QAM/8VSB input channels to (8) QAM and (8)
and control via any standard Web browser IP transport streams.
Model No. AQT8-QAM/IP ....................................... Call for Pricing
